Hasung – Electric Wire Rolling Mill With 5.5HP For Gold Silver Copper

5.5HP Electric Sheet Rolling Mill

Voltage: 380V; Roller size: 112x188mm;

Roller material: Cr12moV.  Speed: 30rpm/min.

Machine size: 820×720×1430mm

weight: approx. 400kg

5.5HP Electric Wire Rolling Mill

Voltage: 380V, 50Hz,

3 phasesPower: Power: 4.15KW (5.5HP);

Roller material: Cr12MoV;

Roller diameter: 112, roller length: 188mm.

Square wire size:  8, 7, 6, 5.5, 5.1, 4.7, 4.35, 4, 3.7, 3.45, 3.2, 3, 2.8, 2.65, 2.5, 2.35, 2.2, 2.05, 1.92, 1.8, 1.68, 1.58, 1.49, 1.43, 1.37, 1.31, 1.25, 1.19, 1.14, 1.1, 1.06, 1.03, 1mm;

Maximum input wire could be 12mm.

Machine size: 820×720×1430mm

weight: approx. 400kg

5.5HP Conbination Rolling Mill (Wire & Sheet)

Voltage: 380v;

Power: 4.0kw; 50hz;

Roller: diameter 112 × width188mm;

Roller material: Cr12MoV;  hardness: 60-61 °;

Machine size: 820×720×1430mm

weight: approx. 400kg;

automatic lubrication; 8 gear transmission, Rolling the maximum thickness of the film is 25mm; 7 square grooves can be opened, which can press 1-8mm square wires; static powder spraying on the frame, the body is plated with decorative hard chrome, and the stainless steel cover is beautiful and practical without rust.
